Nanjing Electronics has recently launched new products in the field of Intelligent Power Modules (IPM). One of these is the launch of a 600V/15A three-phase full-bridge SD15G60, which can be widely used in air-conditioning compressors, refrigerator compressors, and low-power inverters.
SD15G60 is a highly integrated, high-reliability three-phase brushless DC motor drive circuit, which is mainly used in the field of low-power variable frequency drives, such as air conditioners, refrigerators, and washing machines. It has 6 low loss 600V/15A IGBT tubes and 3 high speed semi-bridge high voltage grid drive circuits.
The product also integrates various internal protection functions such as under-voltage, short-circuit, and over-temperature, providing excellent protection and a wide range of safe operation.There are 3 independent negative DC terminals, that is, each phase has an independent negative DC terminal, the current can be detected separately.
In addition, SD15G60 adopts Al2O3 DBC design with high insulation and easy thermal conductivity, with very low thermal resistance.It adopts the DIP-24H package,which is very compact and very convenient to use. It is especially suitable for applications requiring compact installation.
After years of development, Nanjing Electronics has formed seven product groups in the field of motor drive, including HVIC, IPM, MOS, IGBT, PIM, MCU/DSP and AC-DC,covering 250V/500V/600V/1200V、2A-40A、15W-10kW various specifications.Through persistent independent research and development, technological innovation and marketing, key products such as HVIC and IPM have been successfully applied to fans, home appliances, servos, inverters and other fields, breaking the long-term foreign technology monopoly in this field, and also making a contribution to domestic and miniaturization and industrial motor products.
